3 Way Ball Valve
3 Way Ball Valve
| PART NO. | In / Outlet NPT-F | Dimension | Cv | ||||
|---|---|---|---|---|---|---|---|
| L | A | B | H | G | |||
| ARC-BV-6K-4N | 1/4" | 66 | 30 | 6.4 | 44 | 120 | 9.6 |
| ARC-BV-6K-6N | 3/8" | 71 | 32 | 9.5 | 48 | 120 | 9.6 |
| ARC-BV-6K-8N | 1/2" | 84 | 35 | 12 | 55 | 140 | 9.6 |
| ARC-BV-6K-12N | 3/4" | 95 | 50 | 19 | 75 | 192 | 13 |
| ARC-BV-6K-16N | 1" | 110 | 56 | 25 | 80 | 192 | 13 |
| ARC-BV-6K-20N | 1 1/4" | 118 | 70 | 32 | 90 | 195 | 13 |
| ARC-BV-6K-24N | 1 1/2" | 130 | 80 | 38 | 110 | 220 | 16 |
| ARC-BV-6K-32N | 2" | 140 | 98 | 50 | 120 | 270 | 1 |
Above item is manufactured in all the following gradess (S.S, ALLOY, C.S ,DUPLEX , SUPER DUPLEX , HASTELLOY, MONEL, INCONEL)
Note:- All dimensions are in millimeters unless otherwise specified . Dimensions are for reference only , subject to change
